7-13
CARB
FUEL PUMP
INSPECTION
1. Inspect:
• Fuel hose 1
• Fuel delivery hoses 2
• Vacuum hose 3
• Oil delivery hose 4
Clogs/damage → Replace.
2. Check:
• Fuel pump operation
Checking steps:
• Connect the Mity vac 1 to the pulser hose 2.
Mity vac:
90890-06756, YB-35956
• Place a container 3 under the end of the fuel
delivery hoses 4.
• Operate the Mity vac 1 while checking that
fuel flows from the fuel delivery hoses 4.
• If fuel does not flow out, replace the fuel
pump.
INSTALLATION
NOTE:
After installing all parts, refer to “CABLE ROUT-
ING” in CHAPTER 9, to check the cable, lead and
hose routings.
1. Bleed:
• Oil system
Refer to “OIL PUMP” in CHAPTER 2.
SDN7200
SDN7210
To Next Page
