8-15
–+
ELEC
WATER TEMPERATURE AND/OR OIL LEVEL INDICATOR LIGHTS DO NOT COME ON.
Check the water temperature and/or
oil level indicator light bulb(s).
OK NO CONTINUITY Replace the bulb(s).
Check the load control relay.
OK FAULTY Replace the load control relay.
Check for voltage on the condenser coupler.
OK OUT OF SPECIFICATION Correct connection and/or replace the rectifier/
regulator.
Check the condenser.
OK OUT OF SPECIFICATION Replace the condenser.
Check the stator coil.
OK FAULTY Replace the AC magneto.
Check the water temperature
sensor or oil level switch.
OK FAULTY Replace the water temperature sensor or oil level
switch.
Correct the connection and/or
replace the rectifier/regulator and/
or CDI unit.
NOTE:
The indicator lights come on for a few seconds
after the engine starts. If the lights do not come
on, check the indicator light circuit and bulb(s).
SIGNAL SYSTEM
