FRONT BRAKE
4-12
Disassembling the front brake caliper
Order Part name Q’ty Remarks
1 Brake caliper piston 2
2 Brake caliper piston dust seal 2
3 Brake caliper piston seal 2
4 Bleed screw 1
For assembly, reverse the disassemble pro-
cedure.
1
2
3
4
S
S
BF
BF
T
R
.
.
6 Nm (0.6 m • kgf, 4.3 ft • Ibf)
