Yamaha YZ250F(E) - Page 198

ENGINE REMOVAL
5-5
6 Drive chain guide 1
7 Drive sprocket 1
8 Upper engine bracket 2
9 Washer 1 Thickness:2.3 mm (0.09 in)
10 Washer 1 Thickness:1.0 mm (0.04 in)
11 Lower engine bracket 2
12 Pivot shaft 1
13 Engine 1
For installation, reverse the removal proce-
dure.
Removing the engine
Order Part name Q’ty Remarks
New
New
LS
M
8
8
7
6
13
4
5
New
1
12
3
2
11
10
9
55 Nm (5.5 m
•
kgf, 40 ft
•
Ibf)
T
.R
.
