Yamatake MGG14C - Page 83

4 - 30
Relations for Setting Function FXXXX Continued
Introduction
(continued)
2-contact output (DO/DO)
Range function Built-in counter function
Contact input
Contact output function
function
0: Single range X: Not activated X: Not activated X: Not activated
1: Alarm output
4: Self-check result output
5: Empty detection function
6: High/low limit alarm
A: Addition X:
Not activated X: Not activated
1: Alarm output
4: Self-check result output
5: Empty detection function
6: High/low limit alarm
B: Addition with preset X:
Not activated 3: Preset
D: Alarm+Preset output
1: Automatic X: Not activated X:
Not activated 2: Range switching output
switching 7: Alarm+Range switching output
double range 8: Self-check result+Range switching output
9: Empty detection function+Range switching output
A: High/low limit alarm+Range switching output
C: Range switching+Self-check empty detection function
A: Addition X: Not activated 2: Range switching output
7: Alarm+Range switching output
8: Self-check result+Range switching output
9: Empty detection function+Range switching output
A: High/low limit alarm+Range switching output
C: Range switching+Self-check empty detection function
B: Addition with preset X: Not activated B: Range switching+Preset output
3: Normal/ X: Not activated X: Not activated 2: Range switching output
reverse 7: Alarm+Range switching output
automatic 8:
Self-check result+Range switching output
switching 9: Empty detection function+Range switching output
range A: High/low limit alarm+Range switching output
C: Range switching+Self-check empty detection function
A: Addition X: Not activated 2: Range switching output
7: Alarm+Range switching output
8:
Self-check result+Range switching output
9: Empty detection function+Range switching output
A: High/low limit alarm+Range switching output
C: Range switching+Self-check empty detection function
B: Addition with preset X: Not activated B: Range switching+Preset output
C: Normal/reverse X:
Not activated 2: Range switching output
flow integration 7: Alarm+Range switching output
8:
Self-check result+Range switching output
9: Empty detection function+Range switching output
A: High/low limit alarm+Range switching output
C: Range switching+Self-check empty detection function
0: Single range X: Not activated X: Not activated X: Not activated
A: Addition X: Not activated X: Not activated
Range function Built-in counter function Contact input function Contact output function
Without DI/DO
