Parameter List
11
11.21 Defaults by Drive Model and Duty Rating ND/HD
YASKAWA SIEPC71061753C GA500 Technical Manual 471
No.
*1
Name Unit Default
- Drive Model - 2008 2010 2012 2018
C6-01
Normal /
Heavy Duty
Selection
-
HD ND HD ND HD ND HD ND
0 1 0 1 0 1 0 1
o2-04
Drive Model
(KVA)
Selection
Hex. 64 65 66 67
E2-11
(E4-11, E5-
02)
Motor Rated
Power
kW 1.1 1.5 1.5 2.2 2.2 3.0 3.0 3.7
L2-03
Minimum
Baseblock
Time
s 0.4 0.4 0.4 0.5 0.5 0.5 0.5 0.6
L2-04
Powerloss V/f
Recovery
Ramp Time
s 0.3 0.3 0.3 0.3 0.3 0.3 0.3 0.3
L2-05
Undervoltage
Detection Lvl
(Uv1)
- 190 190 190 190 190 190 190 190
L3-02
Stall Prevent
Level during
Accel
% 150 120 150 120 150 120 150 120
L3-06
Stall Prevent
Level during
Run
% 150 120 150 120 150 120 150 120
L3-24
Motor Accel
Time @ Rated
Torque
s 0.142 0.166 0.166 0.145 0.145 0.145 0.145 0.154
L8-02
Overheat
Alarm Level
°C 110 110 110 110 110 110 115 115
L8-09
Output
Ground Fault
Detection
- 0 0 0 0 0 0 0 0
n1-03
Hunting
Prevention
Time Constant
ms 10 10 10 10 10 10 10 10
n3-02
HSB Current
Limit Level
1 150 120 150 120 150 120 150 120
n5-02
Motor Inertia
Acceleration
Time
s 0.142 0.166 0.166 0.145 0.145 0.145 0.145 0.154
*1 Parameters within parentheses are for motor 2.
No.
*1
Name Unit Default
- Drive Model - 2021 2030 2042 2056
C6-01
Normal /
Heavy Duty
Selection
-
HD ND HD ND HD ND HD ND
0 1 0 1 0 1 0 1
o2-04
Drive Model
(KVA)
Selection
Hex. 68 6A 6B 6D
E2-11
(E4-11, E5-
02)
Motor Rated
Power
kW 3.7 5.5 5.5 7.5 7.5 11 11 15
b3-04
V/f Gain
during Speed
Search
% 100 100 100 100 100 100 100 100
b3-06
Speed
Estimation
Current Level
1
- 0.5 0.5 0.5 0.5 0.5 0.5 0.5 0.5
b3-08
Speed
Estimation
ACR P Gain
- 0.5 0.5 0.5 0.5 0.5 0.5 0.5 0.5
b3-26
Direction
Determination
Level
- 1000 1000 1000 1000 1000 1000 1000 1000
b8-03
Energy Saving
Filter Time
s 0.5 0.5 0.5 0.5 0.5 0.5 0.5 0.5
b8-04
Energy Saving
Coefficient
Value
- 122.9 94.75 94.75 72.69 72.69 70.44 70.44 63.13
To Next Page
