11.21 Defaults by Drive Model and Duty Rating ND/HD
472 YASKAWA SIEPC71061753C GA500 Technical Manual
No.
*1
Name Unit Default
- Drive Model - 2021 2030 2042 2056
C6-01
Normal /
Heavy Duty
Selection
-
HD ND HD ND HD ND HD ND
0 1 0 1 0 1 0 1
o2-04
Drive Model
(KVA)
Selection
Hex. 68 6A 6B 6D
E2-11
(E4-11, E5-
02)
Motor Rated
Power
kW 3.7 5.5 5.5 7.5 7.5 11 11 15
C6-02
Carrier
Frequency
Selection
- 3 7 3 7 3 7 3 7
E2-01
(E4-01)
Motor Rated
Current (FLA)
A 14 19.6 19.6 26.6 26.6 39.7 39.7 53
E2-02
(E4-02)
Motor Rated
Slip
Hz 2.73 1.5 1.5 1.3 1.3 1.7 1.7 1.6
E2-03
(E4-03)
Motor No-
Load Current
A 4.5 5.1 5.1 8 8 11.2 11.2 15.2
E2-05
(E4-05)
Motor Line-
to-Line
Resistance
Ω 0.771 0.399 0.399 0.288 0.288 0.23 0.23 0.138
E2-06
(E4-06)
Motor
Leakage
Inductance
% 19.6 18.2 18.2 15.5 15.5 19.5 19.5 17.2
E2-10
(E4-10)
Motor Iron
Loss
W 112 172 172 262 262 245 245 272
E5-01
PM Motor
Code
Selection
- FFFF FFFF FFFF FFFF FFFF FFFF FFFF FFFF
L2-02
Power Loss
Ride Through
Time
s 1 1 1 1 1 1 2 2
L2-03
Minimum
Baseblock
Time
s 0.6 0.7 0.7 0.8 0.8 0.9 0.9 1
L2-04
Powerloss V/f
Recovery
Ramp Time
s 0.3 0.3 0.3 0.3 0.3 0.3 0.3 0.6
L2-05
Undervoltage
Detection Lvl
(Uv1)
- 190 190 190 190 190 190 190 190
L3-02
Stall Prevent
Level during
Accel
% 150 120 150 120 150 120 150 120
L3-06
Stall Prevent
Level during
Run
% 150 120 150 120 150 120 150 120
L3-24
Motor Accel
Time @ Rated
Torque
s 0.154 0.168 0.168 0.175 0.175 0.265 0.265 0.244
L8-02
Overheat
Alarm Level
°C 115 115 105 105 115 115 125 125
L8-09
Output
Ground Fault
Detection
- 0 0 1 1 1 1 1 1
n1-03
Hunting
Prevention
Time Constant
ms 10 10 10 10 10 10 10 10
n3-02
HSB Current
Limit Level
1 150 120 150 120 150 120 150 120
n5-02
Motor Inertia
Acceleration
Time
s 0.154 0.168 0.168 0.175 0.175 0.265 0.265 0.244
*1 Parameters within parentheses are for motor 2.
