YASKAWA CIPR-GA50CB001

Parameter List
11
11.21 Defaults by Drive Model and Duty Rating ND/HD
YASKAWA SIEPC71061753C GA500 Technical Manual 473
No.
*1
Name Unit Default
- Drive Model - 2070 2082
C6-01
Normal / Heavy
Duty Selection
-
HD ND HD ND
0 1 0 1
o2-04
Drive Model (KVA)
Selection
Hex. 6E 6F
E2-11
(E4-11, E5-02)
Motor Rated Power kW 15 18.5 18.5 22
b3-04
V/f Gain during Speed
Search
% 100 100 100 100
b3-06
Speed Estimation
Current Level 1
- 0.5 0.5 0.5 0.5
b3-08
Speed Estimation ACR
P Gain
- 0.5 0.5 0.5 0.5
b3-26
Direction
Determination Level
- 1000 1000 1000 1000
b8-03
Energy Saving Filter
Time
s 0.5 0.5 0.5 0.5
b8-04
Energy Saving
Coefficient Value
- 63.13 57.87 57.87 51.79
C6-02
Carrier Frequency
Selection
- 3 7 3 7
E2-01
(E4-01)
Motor Rated Current
(FLA)
A 53 65.8 65.8 77.2
E2-02
(E4-02)
Motor Rated Slip Hz 1.6 1.67 1.67 1.7
E2-03
(E4-03)
Motor No-Load
Current
A 15.2 15.7 15.7 18.5
E2-05
(E4-05)
Motor Line-to-Line
Resistance
Ω 0.138 0.101 0.101 0.079
E2-06
(E4-06)
Motor Leakage
Inductance
% 17.2 15.7 20.1 19.5
E2-10
(E4-10)
Motor Iron Loss W 272 505 505 538
E5-01
PM Motor Code
Selection
- FFFF FFFF FFFF FFFF
L2-02
Power Loss Ride
Through Time
s 2 2 2 2
L2-03
Minimum Baseblock
Time
s 1 1 1 1
L2-04
Powerloss V/f
Recovery Ramp Time
s 0.6 0.6 0.6 0.6
L2-05
Undervoltage Detection
Lvl (Uv1)
- 190 190 190 190
L3-02
Stall Prevent Level
during Accel
% 150 120 150 120
L3-06
Stall Prevent Level
during Run
% 150 120 150 120
L3-24
Motor Accel Time @
Rated Torque
s 0.244 0.317 0.317 0.355
L8-02 Overheat Alarm Level °C 120 120 135 135
L8-09
Output Ground Fault
Detection
- 1 1 1 1
n1-03
Hunting Prevention
Time Constant
ms 10 10 10 10
n3-02
HSB Current Limit
Level
% 150 120 150 120
n5-02
Motor Inertia
Acceleration Time
s 0.244 0.317 0.317 0.355
*1 Parameters within parentheses are for motor 2.
