12.11 o: Keypad-Related Settings
YASKAWA SIEPC71061753C GA500 Technical Manual 773
■ Log File Configuration
The [Log_Files] folder is created in the root directory of the micro SD card. This is where the log data is stored as
CSV files. Log data files are created in this configuration. The number of rows changes when the number of
selected monitors change.
First Row Drive information
Second Row Log data information
Third Row Log data 1
: Log data 2
: Log data 3
: :
Last Row Log data n
First Row: Drive Information
This example shows the data text strings and data generated for the first row of log data.
Example of generated data: 00,0012,160107111230,GA500,VSVA01010,2,62,1000,000001
No. Item
Number
of
Charac
ters
Example Description
1 Attribute 2 00 [00] shows that the record is a drive information record.
2 File number 4 0012 Generates the [xxx] part (a 3-digit decimal number) of the [GLOG0xxx.csv] filename of the log data
in hexadecimal format.
Example filename of [GLOG0018.csv]: 018 (Dec.) = 0012 (Hex.)
3 Time stamp
*1
12 160107111230 Date file was generated
• Date: 20YY/MM/DD
• Time in 24-hour format: HH:MM:SS
Example data of [160107111230]: 11:12:30 on January 7, 2016
4 Model 5 GA500 Drive model information
5 Software number 9 VSVA01011 Drive software number
6 Control Method Selection 1 2 Setting value (Hex.) of A1-02 [Control Method Selection]
7 Drive capacity 2 62 Setting value (Hex.) of o2-04 [Drive Model (KVA) Selection]
8 Sampling time 5
(Maximum)
1000 Setting value (Dec.) of o5-02 [Log Sampling Interval]
Unit: ms
9 Row number 6 000001 Row number (Hex.) in the data log file
*1 If you do not set the time in the keypad, the text string of [000000000000] is generated to show the time.
Second Row: Log Data Information
This example shows the data text strings and data generated for the second row of log data.
Example of generated data:
01,0012,160107111230,0101,0201,0102,0201,0103,0206,0107,0005,0108,0209,0000,0000,0000,0000,0000,0
000,0000,0000,0000,0000,0000,0000,0000,0000,000002
No. Item
Number of
Characters
Description
1 Attribute 2 [01] shows that the record is a log data information record.
2 File number 4 Generates the [xxx] part (a 3-digit decimal number) of the [GLOG0xxx.csv] filename of the log data in hexadecimal
format.
3 Time stamp 12 Date file was generated
4 Monitor Number 1
*1
4 Monitor number selected by o5-03 [Log Monitor Data 1]
Ex.: 0101 (Dec.) for U1-01
5 Monitor Unit 1
*2
4 Unit code and number of decimal places used for the monitor selected with o5-03
Example when U1-01 = 30.00 Hz:
Number of decimal places = 2, Hz unit code = 01, monitor unit 1 = 0201 (Hex.)
6 Monitor number 2 4 Monitor number (Dec.) selected by o5-04 [Log Monitor Data 2]
7 Monitor Unit 2 4 Unit code and number of decimal places used for the monitor selected with o5-04
: : : :
