YASKAWA GA800 Series User Manual

6 Mechanical Installation
16 YASKAWA TOEPC71061737B GA800 Drive Installation & Primary Operation
Table 6.1 IP20 Exterior and Mounting Dimensions for Models 2004 to 2082
Model
Dimensions mm (in)
W H D W1 W2 H1 H2 d
2004 - 2012
140
(5.51)
260
(10.24)
176
(6.93)
102
(4.02)
102
(4.02)
248
(9.76)
6
(0.24)
M5
2018 - 2042
140
(5.51)
260
(10.24)
211
(8.31)
102
(4.02)
102
(4.02)
248
(9.76)
6
(0.24)
M5
2056
180
(7.09)
300
(11.81)
202
(7.95)
140
(5.51)
140
(5.51)
284
(11.18)
8
(0.32)
M5
2070 - 2082
220
(8.66)
350
(13.78)
227
(8.94)
192
(7.56)
192
(7.56)
335
(13.19)
8
(0.32)
M6
Table 6.2 IP20 Exterior and Mounting Dimensions for Models 4002 to 4060
Model
Dimensions mm (in)
W H D W1 W2 H1 H2 d
4002 - 4005
140
(5.51)
260
(10.24)
176
(6.93)
102
(4.02)
102
(4.02)
248
(9.76)
6
(0.24)
M5
4007 - 4023
140
(5.51)
260
(10.24)
211
(8.31)
102
(4.02)
102
(4.02)
248
(9.76)
6
(0.24)
M5
4031 - 4038
180
(7.09)
300
(11.81)
202
(7.95)
140
(5.51)
140
(5.51)
284
(11.18)
8
(0.32)
M5
4044
220
(8.66)
350
(13.78)
227
(8.94)
192
(7.56)
192
(7.56)
335
(13.19)
8
(0.32)
M6
4060
220
(8.66)
350
(13.78)
246
(9.69)
192
(7.56)
192
(7.56)
335
(13.19)
8
(0.32)
M6

YASKAWA GA800 Series Specifications

General

Series	GA800
Control Method	V/f Control
Overload Capacity	150% for 60 seconds
Communication	Ethernet/IP, Modbus RTU/TCP, PROFIBUS, PROFINET, DeviceNet
Safety	STO (Safe Torque Off)
Enclosure	IP00, IP20, IP55
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheating, Ground Fault, Short Circuit
Enclosure Rating	IP00, IP20, IP55
Voltage Class	200V, 400V
