13 European Standards
YASKAWA TOEPC71061737B GA800 Drive Installation & Primary Operation 93
Model Terminals
Recommended
Gauge
mm
2
Applicable Gauge
(IP20 Applicable
Gauge
*1
)
mm
2
Wire Stripping
Length
*2
mm
Terminal Screw
Tightening Torque
Nm (inlb)
Size Shape
2360
R/L1, S/L2, T/L3 120 × 2P
70 - 150 × 2P
(150 × 2P)
- M12 Hex self-locking nut
35
(310)
U/T1, V/T2, W/T3 120 × 2P
70 - 150 × 2P
(150 × 2P)
- M12 Hex self-locking nut
35
(310)
-, +1 120 × 2P
95 - 185 × 2P
(185 × 2P)
- M12 Hex self-locking nut
35
(310)
+3 70 × 2P
50 - 95 × 2P
(-)
- M12 Hex self-locking nut
35
(310)
120
120 - 240
(-)
- M12 Hex bolt (slotted)
32 - 40
(283 - 354)
2415
R/L1, S/L2, T/L3 120 × 2P
70 - 150 × 2P
(150 × 2P)
- M12 Hex self-locking nut
35
(310)
U/T1, V/T2, W/T3 120 × 2P
70 - 150 × 2P
(150 × 2P)
- M12 Hex self-locking nut
35
(310)
-, +1 120 × 2P
95 - 185 × 2P
(185 × 2P)
- M12 Hex self-locking nut
35
(310)
+3 70 × 2P
50 - 95 × 2P
(-)
- M12 Hex self-locking nut
35
(310)
120
120 - 240
(-)
- M12 Hex bolt (slotted)
32 - 40
(283 - 354)
*1 For IP20 protection, use wires that are in the range of applicable gauges.
*2 Remove insulation from the ends of wires to expose the length of wire shown.
*3 For wire gauges more than 30 mm
2
, tighten to a tightening torque of 4.1 N∙m to 4.5 N∙m (36 in∙lb to 40 in∙lb).
*4 Install a GFCI with this wire gauge to maintain compliance with IEC/EN 61800-5-1:2007.
*5 Terminals - and +1 have two screws. The Recommended Gauge is the wire gauge for one terminal.
*6 A junction terminal is necessary to connect a braking unit (CDBR series) to terminals - and +3.
Three-Phase 400 V Class
Model Terminal
Recommended
Gauge
mm
2
Applicable Gauge
(IP20 Applicable
Gauge
*1
)
mm
2
Wire Stripping
Length
*2
mm
Terminal Screw
Tightening Torque
Nm (inlb)
Size Shape
4002
R/L1, S/L2, T/L3 2.5
2.5 - 10
(2.5 - 10)
10 M4 Slotted (-)
1.5 - 1.7
(13.5 - 15)
U/T1, V/T2, W/T3 2.5
2.5 - 10
(2.5 - 10)
10 M4 Slotted (-)
1.5 - 1.7
(13.5 - 15)
-, +1, +2 2.5
2.5 - 16
(2.5 - 16)
18 M5 Slotted (-)
2.3 - 2.5
(19.8 - 22)
*3
B1B2 2.5
2.5 - 4
(2.5 - 4)
10 M4 Slotted (-)
1.5 - 1.7
(13.5 - 15)
2.5
*4
2.5 - 10
(-)
- M4 Phillips/slotted combo
1.2 - 1.5
(10.6 - 13.3)
4004
R/L1, S/L2, T/L3 2.5
2.5 - 10
(2.5 - 10)
10 M4 Slotted (-)
1.5 - 1.7
(13.5 - 15)
U/T1, V/T2, W/T3 2.5
2.5 - 10
(2.5 - 10)
10 M4 Slotted (-)
1.5 - 1.7
(13.5 - 15)
-, +1, +2 2.5
2.5 - 16
(2.5 - 16)
18 M5 Slotted (-)
2.3 - 2.5
(19.8 - 22)
*3
B1B2 2.5
2.5 - 4
(2.5 - 4)
10 M4 Slotted (-)
1.5 - 1.7
(13.5 - 15)
2.5
*4
2.5 - 10
(-)
- M4 Phillips/slotted combo
1.2 - 1.5
(10.6 - 13.3)
