17 Firmware Upgrade Procedure
1) Turn on the SUP DIP Switch.
2) Reboot the controller.
3) Use Internet Explorer to connect to the MP23iec Web
server. Type in the IP address of the controller in the brower’s
address bar.
4) Under the “Maintenance” section at the left of the screen, select
“Upgrade Firmware.”
5) Browse the appropiate firmware “zip” file.
6) Press the “upload” button.
7) When the controller upgrade is complete, the screen will indicate
to switch off the SUP DIP switch and reboot the controller.
8) The firmware update is complete.
More detailed instructions (including firmware history) are available for
download from Yaskawa’s website: www.yaskawa.com/iecSupport
