Dimensions
1.4.1 MP2300Siec Controller
7
1.4
Dimensions
1.4.1
MP2300Siec Controller
/25KGE
Relay connector (2P)
Power connector (3P)
T
erminating resistor
for MECHA
TROLINK
(attachment)
Model nameplate
DIN rail (35mm width)
(10: when DIN
rail is attached)
Units: mm
64
(42)
108
734-YE102
721-203/026-000
130
(9)
(14: when released)
8
10
