9.1 Indicators
37
9 LED Outputs
9.1 Indicators
The following table shows the indicators that show the operating status
of the controller and error information.
Indicator Color Status
RDY
Green
Lit during normal operation.
RUN
Green
Lit during execution of user program.
ALM
Red
Lit/blinking when warning occurs.
ERR
Red
Lit/blinking when malfunction occurs.
MTX
Green
Lit when transmitting MECHATROLINK-II data.
BAT
Red
Lit during battery alarm.
TRX
Green
Lit when transmitting or receiving Ethernet data.
IP
Green
Lit when an IP address setting is completed.
