14.3 DO–01 (Digital Output) Module
14.3.1 Appearance/Indicators
62
14.3 DO–01 (Digital Output) Module
14.3.1 Appearance/Indicators
14.3.2 Module Functions
The DO–01 module is equipped with 64 digital outputs.
14.3.3 Output Circuit Specifications
The following table shows the DO-01 Module output circuit
specifications.
Item Specifications
Outputs
64 points
Output Format Transistor/open collector, sink mode output
Isolation Method
Photocoupler
Output Voltage
+ 24VDC (+19.2 to +28.8V)
Output Current
100 mA Max
Leakage Current When OFF
0.1 mA Max
ON Time/OFF Time
ON: 0.5 ms Max
OFF: 1 ms Max
Number of Commons
8 points
Protection Circuit
Fuse connected to each common line
Fuse Rating
1A
Error Detection
Fuse blowout detection
