6.1 RLY OUT Connector Details
31
6 EStop (RLY OUT) - MP2300Siec only
6.1 RLY OUT Connector Details
The RLY OUT connector is a terminal for outputting state and NO
contact relay output. A circuit between terminals is closed when RDY
LED is lit, and opens when it is unlit.
RLY OUT Connector Specifications and Pin Array
The following table provides the RLY OUT connector specifications.
The following table shows the RLY OUT connector pin array.
The following table provides the RLY OUT connector contact
ratings.
RLY OUT Connection Cable
For the RLY OUT connection cable, use a cable of line size AWG28
to AWG14 (0.08 mm
2
to 1.5 mm
2
), maximum sheath diameter of3.4
mm. The RLY OUT connector cable is similar in manufacture to the
24VDC power supply cable.
A state when RDY LED is lit indicates that a controller is operating normally. It
does not indicate that a user program is running.
Name
Connector
Name
Number
of Pins
Connector Model
Module Side Cable Side Manufacturer
RLY OUT RLY OUT
2 734-162 734-YE102 Wago Corporation
Pin Number Signal Name Description
1OUT
Operating normally: Closed
Error occurred: Opened
2OUT
RLY
OU
T
Input Voltage Current Capacity
24VDC
0.5A (resistance load)
0.25A (induced load)
125VAC
0.4A (resistance load)
0.2A (induced load)
