1.3 MP23iec Modules
The following table shows the names and specifications of the
Controller and Option Modules.
Group Name Description Model Specifications
Option Modules
Motion
Modules
None currently supported
I/O Modules
Analog Input
Module
AI-01 JAPMC-AN2300 Analog input, 8 channels
Analog Output
Module
AO-01 JAPMC-AN2310 Analog output, 4 channels
Output Module DO-01 JAPMC-DO2300 64 outputs (sink mode output)
I/O Module LIO-01 JAPMC-IO2300
16 inputs, 16 outputs (sink mode
output)
1 encoder input
I/O Module LIO-02 JAPMC-IO2301
16 inputs, 16 outputs (source mode
output)
1 encoder input
I/O Module LIO-04 JAPMC-IO2303
32 inputs, 32 outputs
(sink mode output)
I/O Module LIO-05 JAPMC-IO2304
32 inputs, 32 outputs (source mode
output)
Multi-function
Option Card
LIO-06 JAPMC-IO2305-E
8 digital inputs, 8 digital outputs (sink
mode), 1 analog input, 1 analog
output, 1 encoder input
