4.1 Component Model Numbers
17
4 Part Numbers
4.1 Component Model Numbers
System Components
Type Model Part Number Note
Controller Base
MP2300Siec
PMC-U-MP23S04 4 axis, no I/O module
PMC-U-MP23S08 8 axis, no I/O module
PMC-U-MP23S16 16 axis, no I/O module
PMC-U-MP23S04L1 4 axis, LIO-01 module
PMC-U-MP23S08L1 8 axis, LIO-01 module
PMC-U-MP23S16L1 16 axis, LIO-01 module
PMC-U-MP23S04L2 4 axis, LIO-02 module
PMC-U-MP23S08L2 8 axis, LIO-02 module
PMC-U-MP23S16L2 16 axis, LIO-02 module
MP2310iec
PMC-U-MP23104 4 axis, no I/O module
PMC-U-MP23108 8 axis, no I/O module
PMC-U-MP23116 16 axis, no I/O module
Accessories
Battery JZSP-BA01 Replacement
Panel Mounting Bracket JEPMC-OP2300S-E Only required for screw mounting
DIN Rail Clips for
MP2000iec
JEPMC-OP300 Set of 2 clips
RLY OUT Connector 734-YE102 Replacement (MP2300Siec only)
Power Supply
Connector
721-203/026 Replacement
I/O Option cards
AI-01 (Analog inputs) JAPMC-AN2300
MP2300Siec:
Select one local I/O module
MP2310iec:
Select up to 3 local I/O modules
AO-01 (Analog outputs) JAPMC-AN2310-E
DO-01 (Digital outputs) JAPMC-DO2300
LIO-01 (16 in, 16 out,
enc)
JAPMC-IO2300
LIO-02 (16 in, 16 out,
enc)
JAPMC-IO2301
LIO-04 (32 in, 32 out) JAPMC-IO2303
LIO-05 (32 in, 32 out) JAPMC-IO2304
LIO-06 (Multi-function
card)
JAPMC-IO2305-E
Other
I/O
IO2310/IO2330
(64 Point I/O Module)
JEPMC-IO2310
JEPMC-IO2330
IO2310: Sinking Output Type
IO2330: Sourcing Output Type
Ethernet Cable
N/A Use common shielded ethernet cable
