YASKAWA MP2300Siec User Manual

3.3
Specifications of Controller
MP2310iec Hardware Specifications
16
MP2310iec Hardware Specifications
Item Specifications
Classification
Basic Module
Name
MP2310
Model Number
JEPMC-MP2310-E
Power
Unit
Input Voltage
24VDC (
 20%)
Input Current*
1 A max. (during input/output rating)
Inrush Current*
40 A max. (full discharge state, during output rating, or the secondary
output of the external 24V power supply is turned ON)
Rated Voltage
5.0 V
Rated Current
2.0 A
Output Current Range
0.0 to 2.0 A
Constant Voltage
Precision
2% max. (including input voltage and output load fluctuations)
Battery
Battery for memory retention attachable
Flash Memory
12 MB (User area 7.5 MBytes)
SDRAM
32 MB
SRAM
2 MB: M registers, S registers, trace memory, alarm history (battery backup)
Motion Network
MECHATROLINK: 1 channel
SERVOPACK and I/O for up to 21 stations connectable (SERVOPACK
for up to 16 axes)
Baud rate: 4 Mbps (MECHATROLINK-I) or 10 Mbps
(MECHATROLINK-II)
Communication Function
Ethernet: 100BASE-TX/10BASE-T
Calendar
Seconds to year timer
(Battery backup)
Connectors
POWER: Power supply connector
M-I/II: MECHATROLINK connector
Ethernet: Ethernet connector
Indicators
RDY(green), RUN(green), ALM(red), ERR(red), MTX(green),
BAT(red), TRX(green), IP(green), LINK(yellow), 100M(green)
Switches
STOP, SUP, INIT, CNFG, MON, TEST, E-INIT, and E-TEST
Current Consumption
1A max.
Dimensions (mm)
120  130  108 (W  H  D)
Mass
450 g
 For the external 24V power supply, select a power supply which satisfies the
specifications below as well as the rated current (not more than 1A):
 Allowable output load capacity: 1200F or more
 Overcurrent detection is automatically restored by removing causes
 However, except that the primary side (AC side) of the external 24V power
supply is turned ON/OFF.
Note: Recommended external 24V power supply: RTW24-2R2 (manufactured by TDK)
