3.3 Specifications of Controller
MP2300Siec Hardware Specifications
15
3.3 Specifications of Controller
MP2300Siec Hardware Specifications
Item Specifications
Classification
Controller
Name
MP2300Siec
Model Number
PMC–U–MP23S (See page 17)
Power
Unit
Input Voltage
24VDC (
 20%)
Input Current
1A Max (during input/output rating)
Inrush Current
40A Max (full discharge state, during output rating, or the secondary
output of the external 24V power supply is turned ON)
Rated Voltage
5.0V
Rated Current
2.0A
Output Current Range
0.0 to 2.0A
Constant Voltage
Precision
2% Max (including input voltage and output load fluctuations)
Battery
Battery for memory retention attachable
Motion Network
MECHATROLINK-II: 1 channel
SERVOPACK and I/O for up to 20 slave nodes connectable
(SERVOPACK for up to 16 axes)
Baud rate: 10 Mbps (MECHATROLINK-II)
Communication Function
Ethernet: 100BASE-TX/10BASE-T
Calendar
Seconds to year timer
(Battery backup)
Connectors
Power supply to Ethernet RLY OUT
Indicators
RDY(green), RUN(green), ALM(red), ERR(red), MTX(green),
BAT(red), TRX(green), IP(green), LINK(yellow), 100M(green)
Switches
STOP, SUP, INIT, CNFG, MON, TEST, E-INIT, E-TEST
Current Consumption
1A Max
Dimensions (mm)
64  130  108 (W  H  D)
Mass
390 g
 For the external 24V power supply, select a power supply which satisfies the
specifications below as well as the rated current (not more than 1A):
 Allowable output load capacity: 1200F or more
 Overcurrent detection is automatically restored by removing causes
 However, except that the primary side (AC side) of the external 24V power
supply is turned ON/OFF.
