9.1 System Configuration and Connection Example for SERVOPACK with Fully-closed Loop Control
9-7
9
Fully-closed Loop Control
9.1.5 Connection Example of External Encoder by Mitutoyo
The serial converter unit is not needed when using the external encoder made by Mitutoyo Corporation.
CN31
JZSP-CLP70--E Connection cable
by Mitutoyo Corp.
External encoder
by Mitutoyo Corp.
ABS ST78A
SERVOPACK with
option module for
fully-closed loop
control
