1.6 SERVOPACK Model Designation
Select the SERVOPACK according to the applied servomotor.
SGDV
Series
SGDV Σ-V Series
1st + 2nd + 3rd digits: Current
Voltage Code
Max. Allowable
Motor Capacity
(kW)
100 V
R70 0.05
R90 0.1
2R1 0.2
2R8 0.4
200 V
R70 0.05
R90 0.1
1R6 0.2
2R8 0.4
3R8 0.5
5R5 0.75
7R6 1
120 1.5
180 2
200 3
330 5
470 6
550 7.5
590 11
780 15
400 V
1R9 0.5
3R5 1
5R4 1.5
8R4 2
120 3
170 5
210 6
260 7.5
280 11
370 15
4th digit: Voltage
Code Voltage
F 100 V
A 200 V
D 400 V
5th + 6th digits: Interface Specifications
Code Interface
01
Analog voltage and pulse train
reference, rotational servomotor
11
MECHATROLINK-II communications
reference, rotational servomotor
05
Analog voltage and pulse train
reference, linear servomotor
15
MECHATROLINK-II communications
reference, linear servomotor
8th to 13th digits: Option
Blank Base-mounted type (standard)
001000
Rack-mounted type or duct-
ventilated type (option)
–
7th digit: Design
Revision Order
1st + 2nd +
3rd digits
4th
digit
5th + 6th
digits
7th
digit
2R8 A
01
A
8th to13th digits
