11.4 Parameter Recording Table
11-33
11
Appendix
Pn506 0 ms
Brake Reference
-
Servo OFF Delay
Time
Immediately
Pn507
100 min
-1
Brake Reference Output Speed Level Immediately
Pn508 500 ms
Waiting Time for Brake Signal When
Motor Running
Immediately
Pn509 20 ms Instantaneous Power Cut Hold time Immediately
Pn50A 2100 Input Signal Selection 1 After restart
Pn50B 6543 Input Signal Selection 2 After restart
Pn50C 8888 Input Signal Selection 3 After restart
Pn50D 8888 Input Signal Selection 4 After restart
Pn50E 3211 Output Signal Selection 1 After restart
Pn50F 0000 Output Signal Selection 2 After restart
Pn510 0000 Output Signal Selection 3 After restart
Pn511 8888 Reserved After restart
Pn512 0000 Output Signal Inverse Setting After restart
Pn513 0000 Reserved After restart
Pn51B
1000
reference
unit
Excessive Error Level Between Ser-
vomotor and Load Positions
Immediately
Pn51E 100%
Excessive Position Error Warning
Level
Immediately
Pn520
5242880
reference
unit
Excessive Position Error Alarm
Level
Immediately
Pn522
7
reference
unit
Positioning Completed Width Immediately
Pn524
1073741824
reference
unit
NEAR Signal Width Immediately
Pn526
5242880
reference
unit
Excessive Position Error Alarm
Level at Servo ON
Immediately
Pn528 100 %
Excessive Position Error Warning
Level at Servo ON
Immediately
Pn529
10000 min
-1
Speed Limit Level at Servo ON Immediately
Pn52A 20 %
Multiplier per One Fully-closed
Rotation
Immediately
Pn52B 20% Overload Warning Level Immediately
Pn52C 100%
Derating of Base Current at Detecting
Overload of Motor
After restart
Pn52F 0FFF Monitor Display at Power ON Immediately
Pn530 0000
Program JOG Operation Related
Switch
Immediately
Pn531
32768
reference
unit
Program JOG Movement Distance Immediately
Pn533
500 min
-1
Program JOG Movement Speed Immediately
Pn534 100 ms
Program JOG Acceleration/Decelera-
tion Time
Immediately
Pn535 100 ms Program JOG Waiting Time Immediately
Parame-
ter
Factory
Setting
Name
When
Enabled
