YASKAWA Varispeed E7 User Manual

User Constant Tables
5-27
 Multi-function Contact Outputs: H2
Multi-function Contact Output Functions
19 PI control disable (ON: PI control disabled) 6-86
1B
Constants write enable (ON: All constants can be written-in. OFF: All constants are write pro-
tected.)
6-109
1C Trim control increase (ON: d4-02 frequency is added to analog frequency reference.) 6-58
1D Trim control decrease (ON: d4-02 frequency is subtracted from analog frequency reference.) 6-58
1E Analog frequency reference sample/hold 6-59
20 to 2F
External fault
Input mode: NO contact/NC contact, Detection mode: Normal/during operation
6-62
30 PI control integral reset (reset when reset command is input or when stopped during PI control) 6-86
31 PI control integral hold (ON: Hold) 6-86
34 PI soft starter disable (ON: disabled) 6-86
35 PI input characteristics switch 6-86
36 Operation Source Option/Inverter selection 2 (ON: inverter settings) 6-60
60 Motor preheat command (ON: Performs motor preheat) 6-14
61 External search command 1 (ON: Speed search from maximum output frequency) 6-40
62 External search command 2 (ON: Speed search from set frequency) 6-40
64 External speed search command 3 6-39
65 KEB (deceleration at momentary power loss) command (NC contact) –
66 KEB (deceleration at momentary power loss) command (NO contact) –
67 Communications test mode 6-81
68 High-slip braking (HSB) 6-101
69 Jog Frequency 2 6-8
6A Drive enable (NC, ON: Drive enabled, OFF: Drive disabled 6-53
6B Operation Source Communication/Inverter selection (ON: RS-422/485 port) 6-60
6C Operation Source Communication/Inverter selection 2 (ON: inverter settings) 6-60
6D AUTO mode selection (ON: AUTO mode active) 6-61
6E HAND mode selection (ON: HAND mode active) 6-61
6F Maintenance Mode –
70 Bypass Drive Enable 6-53
Con-
stant
Number
Name Description
Setting
Range
Factory
Setting
Change
during
Opera-
tion
Access
Level
MEMO-
BUS
Register
Page
H2-01
Terminal M1-M2
function selection
Multi-function contact
output 1
0 to 38 0 No A 40BH –
H2-02
Terminal M3-M4
function selection
Multi-function contact
output 2
0 to 38 1 No A 40CH –
Setting
Value
Function
Page
0 During run (ON: run command is ON or voltage is being output) 6-63
1 Zero-speed 6-64
Setting
Value
Function
Page
