User Constant Tables
5-49
400 V Class Inverters
Con-
stant
Number
Name Unit Factory Setting
– Inverter Capacity kW 0.4 0.75 1.5 2.2 3.7 4.0 5.5 7.5 11 15
o2-04 kVA selection – 20 21 22 23 24 25 26 27 28 29
b8-04
Energy-saving coeffi-
cient
–
576.40 447.40 338.80 313.60 245.80 236.44 189.50 145.38 140.88 126.26
C6-02
Carrier frequency selec-
tion
*
–6666666666
E2-01 Motor rated current A 1.00 1.60 3.10 4.20 7.00 7.00 9.80 13.30 19.9 26.5
E2-03 Motor no-load current A 0.60 0.80 1.40 1.50 2.30 2.30 2.60 4.00 5.6 7.6
E2-05
Motor line-to-line resis-
tance
Ω
38.198 22.459 10.100 6.495 3.333 3.333 1.595 1.152 0.922 0.550
L2-02
Momentary power loss
ridethru time
s 0.1 0.1 0.2 0.3 0.5 0.5 0.8 0.8 1.0 2.0
L2-03
Min. baseblock (BB)
time
s 0.1 0.2 0.3 0.4 0.5 0.6 0.6 0.7 0.8 0.9
L2-04 Voltage recovery time s 0.3 0.3 0.3 0.3 0.3 0.3 0.3 0.3 0.3 0.3
L8-02 Overheat pre-alarm level °C95959595959595959595
Con-
stant
Number
Name Unit Factory Setting
– Inverter Capacity kW 18.5 22 30 37 45 55 75 90 110 132
o2-04 kVA selection – 2A 2B 2C 2D 2E 2F 30 31 32 33
b8-04
Energy-saving coeffi-
cient
–
115.74 103.58 92.54 76.32 71.56 67.20 46.20 41.22 36.23 33.18
C6-02
Carrier frequency selec-
tion
*
–6644443332
E2-01 Motor rated current A
32.9 38.6 52.3 65.6 79.7 95.0 130.0 156.0 190.0 223.0
E2-03 Motor no-load current A
7.8 9.2 10.9 19.1 22.0 24.0 36.0 40.0 49.0 58.0
E2-05
Motor line-to-line resis-
tance
Ω
0.403 0.316 0.269 0.155 0.122 0.088 0.092 0.056 0.046 0.035
L2-02
Momentary power loss
ridethru time
s 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0
L2-03
Min. baseblock (BB)
time
s 1.0 1.0 1.1 1.1 1.2 1.2 1.3 1.5 1.7 1.7
L2-04 Voltage recovery time s 0.6 0.6 0.6 0.6 0.6 1.0 1.0 1.0 1.0 1.0
L8-02 Overheat pre-alarm level °C959595959510095110110110
