Multi-function Output (H2-01 to H2-05)
L6-03
Torque detec-
tion time 1
Sets the overtorque/undertorque
detection time in 1-second units.
0.0 to
10.0
0.1 s No A A A A A 4A3H
Torq Det 1
Time
L6-04
Torque detec-
tion selection 2 Multi-function output for over-
torque detection 1 is output to
multi-function contact output
when overtorque detection 1 NO
or overtorque detection 1 NC is
selected. Multi-function output
for overtorque detection 2 is out-
put to multi-function contact out-
put when overtorque detection 2
NO or overtorque detection 2 NC
is selected.
0 to 8 0 No A A A A A 4A4H
Torq Det 2 Sel
L6-05
Torque detec-
tion level 2
0 to
300
150% No A A A A A 4A5H
Torq Det 2 Lvl
L6-06
Torque detec-
tion time 2
0.0 to
10.0
0.1 s No A A A A A 4A6H
Torq Det 2
Time
Set-
ting
Value
Function
Control Methods
V/f
V/f
with
PG
Open
Loop
Vec-
tor
1
Flux
Vec-
tor
Open
Loop
Vec-
tor
2
B
Overtorque/undertorque detection 1 NO (NO contact: Overtorque/undertorque detec-
tion at ON)
Yes Yes Ye s Yes Ye s
17
Overtorque/undertorque detection 1 NC (NC Contact: Overtorque/undertorque detec-
tion at OFF)
Yes Yes Ye s Yes Ye s
18
Overtorque/undertorque detection 2 NO (NO Contact: Overtorque/undertorque detec-
tion at ON)
Yes Yes Ye s Yes Ye s
19
Overtorque/undertorque detection 2 NC (NC Contact: Overtorque/undertorque detec-
tion at OFF)
Yes Yes Ye s Yes Ye s
Con-
stant
Number
Name
Description
Setting
Range
Factory
Setting
Change
during
Opera-
tion
Control Methods
MEMO
BUS
Regis-
ter
Display
V/f
V/f
with
PG
Open
Loop
Vector
1
Flux
Vec-
tor
Open
Loop
Vector
2
