Conformance to UL Standard
10-11
10
Conformance to UL Standard
To comply with UL standard, follow the appropriate installation instructions.
îš„Installation Site
Install the Inverter in a pollution degree 2 environment or equivalent.
îš„Specification of Closed-Loop Connector
The closed-loop connectors must be installed on conductors before installing to terminal blocks.
Use UL Listed closed-loop connectors shown below.
Table 10.2 JST Closed-Loop Connector Model
Inverter
Model CIMR-G7A
JST Kit P/N
Input Output
27P5 14-5 14-5
2015 38-8 38-8
2018 60-8 38-8
2022 60-8 60-8
2030 80-10 80-10
2037 100-10 100-10
2045 60-10 (2perPh) 60-10 (2perPh)
2055 80-12 (2perPh) 80-10 (2perPh)
2075 150-12 (2perPh) 100-12 (2perPh)
2090 150-12 (2perPh) 150-12 (2perPh)
2110 200-12 (2perPh) 150-12 (2perPh)
4011 8-5 8-5
4015 14-5 14-5
4018 14-6 14-6
4022 22-6 22-6
4030 38-8 22-8
4037 38-8 38-8
4045 60-8 60-8
