9-2
Standard Inverter Specifications
The standard Inverter specifications are listed by capacity in the following tables.
 Specifications by Model
Specifications are given by model in the following tables.
200 V Class
* 1. The maximum applicable motor output is given for a standard 4-pole Yaskawa motor. When selecting the actual motor and Inverter, be sure that the Inverter's
rated current is applicable for the motor's rated current.
* 2. The voltage of the cooling fan for 200 V Class Inverters of 30 kW is three-phase, 200, 208, or 220 V at 50 Hz or 200, 208, 220, or 230 V at 60 Hz.
* 3. A 3-wire transformer is required on the power supply for 12-phase rectification.
Table 9.1 200 V Class Inverters
Model Number CIMR-G7A  20P4 20P7 21P5 22P2 23P7 25P5 27P5 2011 2015 2018 2022 2030 2037 2045 2055 2075 2090 2110
Max. applicable motor output
(kW)
0.4 0.75 1.5 2.2 3.7 5.5 7.5 11 15 18.5 22 30 37 45 55 75 90 110
Rated input current (A) 3.8 7.2 9.6 14.4 22 32 40 59 79 88 106 143 176 201 246 330 394 457
Rated output capacity
(kVA)
1.22.33.04.66.910131925303750617085110140160
Rated output current (A) 3.2 6 8 12 18 27 34 49 66 80 96 130 160 183 224 300 358 415
Max. output voltage (V)
3-phase; 200, 208, 220, 230, or 240 VAC
(Proportional to input voltage.)
Max. output frequency
(Hz)
Frequencies supported up to 400 Hz using constant setting
Rated voltage (V)
Rated frequency (Hz)
3-phase, 200/208/220/230/240 VAC, 50/60 Hz
*2
Allowable voltage fluctua-
tion
+ 10%, - 15%
Allowable frequency fluc-
tuation
±5%
Measures for
power supply
harmonics
DC reactor Optional Built in
12-phase rec-
tification
Not possible
Possible
*3
O
utput rat
i
ngsPower supp
l
y c
h
aracter
i
st
i
cs
