YASKAWA Varispeed V7 - Page 75

74
Byte 0,
bit 3
Te r min al
S4
Inputs the function set for the Inverter’s
multi-function input terminal S4. Set the
function of multi-function input terminal
S4 with Inverter constant n053.
0: Terminal S4 function OFF
1: Terminal S4 function ON
Byte 0,
bit 4
Te r min al
S5*
Inputs the function set for Inverter con-
stant n054 (Multi-function Input Selec-
tion 5.)
0: Terminal S5 function OFF
1: Terminal S5 function ON
Byte 0,
bit 5
Te r min al
S6*
Inputs the function set for Inverter con-
stant n055 (Multi-function Input Selec-
tion 6.)
0: Terminal S6 function OFF
1: Terminal S6 function ON
Byte 0,
bit 6
Te r min al
S7*
Inputs the function set for Inverter con-
stant n056 (Multi-function Input Selec-
tion 7.)
0: Terminal S7 function OFF
1: Terminal S7 function ON
Byte 1,
bit 0
External
Fault
External fault (EF0) input from communi-
cations.
0: ---
1: External fault (EF0)
Byte 1,
bit 1
Fault Reset Resets the Inverter from fault status.
0: ---
1: Reset fault.
Data Name Contents
