Yealink SIP-T43U Administrator's Guide

Administrator’s Guide for SIP-T2 Series/T4 Series/T5 Series/CP920 IP Phones
171
Codec Packetization Time (Minimum) Packetization Time (Maximum)
opus 10ms 20ms
iLBC_15_2kpbs 20ms, 40ms, 60ms
iLBC_13_33kpbs 30ms, 60ms
PTime Configuration
The following table lists the parameter you can use to configure the PTime.
Parameter
account.X.ptime
[1]
<MAC>.cfg
Description
It configures the ptime (in milliseconds) for the codec.
Permitted
Values
0-Disabled
10-10
20-20
30-30
40-40
50-50
60-60
Default
20
Web UI
Account > Advanced > PTime (ms)
[1]
X is the account ID. For T57W/T54W/T48U/T48S/T48G/T46U/T46S/T46G/T29G, X=1-16; for
T53W/T53/T43U/T42G/T42U/T42S, X=1-12; for T41P/T41S/T27G, X=1-6; for T40P/T40G/T23P/T23G, X=1-3; for T21
(P) E2, X=1-2; for T19(P) E2/CP920, X=1.
Early Media
The early media refers to the media (for example, audio and video) played to the caller before a SIP call is actually
established.
Current implementation supports early media through the 183 message. When the caller receives a 183 message
with SDP before the call is established, a media channel is established. This channel is used to provide the early
media stream for the caller.
You can also configure 180 ring workaround which defines whether to deal with the 180 message received after
the 183 message. When the caller receives a 183 message, it suppresses any local ringback tone and begins to
play the media received. 180 ring workaround allows the phones to resume and play the local ringback tone upon
a subsequent 180 message received.
Topic
Early Media Configuration
Early Media Configuration
The following table lists the parameters you can use to configure the early media.
Parameter
phone_setting.early_media.rtp_sniffer.timeout
[1]
<y0000000000xx>.cfg

Yealink SIP-T43U Specifications

General

Mounting	Desk/Wall
Handset type	Wired handset
Product type	IP Phone
Product color	Gray
Wall mountable	Yes
Sustainability certificates	REACH, RoHS
AC adapter input voltage	100 - 240 V
AC adapter output current	1.2 A
AC adapter output voltage	5 V
Power consumption (typical)	2.2 W
Bluetooth version	4.1
Networking standards	IEEE 802.1Q, IEEE 802.1p, IEEE 802.1x, IEEE 802.3af
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Supported network protocols	FTP/TFTP/HTTP/HTTPS, IPv6, LLDP/CDP/DHCP VLAN
USB 2.0 ports quantity	2
Lines quantity	12 lines
Phonebook capacity	1000 entries
Number of VoIP accounts	12
Voice codecs	AGC, AJB, AMR-NB, AMR-WB, G.711Mu, G.711a, G.723.1, G.726, G.729ab, OPUS, PLC, VAD, iLBC
Number of handles included	1 pc(s)
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 95 %
Display diagonal	3.7 \
Display resolution	360 x 160 pixels
Dual-Tone Multi-Frequency (DTMF) modes	In-band, Out-of band, SIP info
Harmonized System (HS) code	85171800

Weight and Dimensions

Depth	206.2 mm
Width	224.9 mm
Height	174.9 mm
Package depth	223 mm
Package width	246 mm
Package height	120 mm
