Yealink SIP-T43U Administrator's Guide

Advanced Features
442
Example
features.pickup.blf_visual_enable = 1
features.pickup.blf_audio_enable = 1
When the monitored line receives an incoming call, the phone screen shows an incoming call to the monitored line
(for example, “6001<-6002”, 6001 is the monitored extension which receives an incoming call from 6002) (from
1008 to 1001), the following occurs on the phone:
l The phone plays a specific alert tone.
l The BLF key LED flashes red. On the T57W/T48U/T48S/T48G IP phone, the icon / flashes.
l The caller ID appears on the phone screen.
The following shows a visual alert for monitor line on T46S/G phones:
You can pick up the call to the monitored line, place a call to the monitored line, place a new call or back to the idle
screen.
LED Mode for BLF/BLF List Key
BLF LED Mode provides five kinds of definition for the BLF/BLF List key LED status. As there is no hard line key on
T57W/T48U/T48S/T48G phones, BLF LED mode configuration is applicable to any phones and expansion module,
except T57W/T48U/T48S/T48G and T19(P) E2/CP920 phones.
Topics
Supported BLF LED Modes
BLF LED Mode Configuration
Supported BLF LED Modes
The following table lists the LED statuses of the BLF/BLF list key when BLF LED Mode is set to 0, 1, 2, 3 or 4 respect-
ively. The default value of BLF LED mode is 0.
Line key/Expansion Module Key LED (configured as a BLF key or a BLF List key and BLF LED Mode is set to 0)
LED Status Description
Solid green The monitored user is idle.
Fast-flashing red
(200ms)
The monitored user receives an incoming call.
Solid red
The monitored user is dialing.
The monitored user is talking.
The monitored user’s conversation is placed on hold (This LED status requires server sup-
port).
Slowly-flashing red (1s) The call is parked against the monitored user’s phone number.

Yealink SIP-T43U Specifications

General

Mounting	Desk/Wall
Handset type	Wired handset
Product type	IP Phone
Product color	Gray
Wall mountable	Yes
Sustainability certificates	REACH, RoHS
AC adapter input voltage	100 - 240 V
AC adapter output current	1.2 A
AC adapter output voltage	5 V
Power consumption (typical)	2.2 W
Bluetooth version	4.1
Networking standards	IEEE 802.1Q, IEEE 802.1p, IEEE 802.1x, IEEE 802.3af
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Supported network protocols	FTP/TFTP/HTTP/HTTPS, IPv6, LLDP/CDP/DHCP VLAN
USB 2.0 ports quantity	2
Lines quantity	12 lines
Phonebook capacity	1000 entries
Number of VoIP accounts	12
Voice codecs	AGC, AJB, AMR-NB, AMR-WB, G.711Mu, G.711a, G.723.1, G.726, G.729ab, OPUS, PLC, VAD, iLBC
Number of handles included	1 pc(s)
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 95 %
Display diagonal	3.7 \
Display resolution	360 x 160 pixels
Dual-Tone Multi-Frequency (DTMF) modes	In-band, Out-of band, SIP info
Harmonized System (HS) code	85171800

Weight and Dimensions

Depth	206.2 mm
Width	224.9 mm
Height	174.9 mm
Package depth	223 mm
Package width	246 mm
Package height	120 mm
