Yealink SIP-T43U Administrator's Guide

Administrator’s Guide for SIP-T2 Series/T4 Series/T5 Series/CP920 IP Phones
83
Yealink phones can obtain the provisioning server address during startup. Then the phones first download boot
files and configuration files from the provisioning server and then resolve and update the configurations written in
configuration files. This entire process is called auto provisioning. For more information on auto provisioning, refer
to Yealink SIP IP Phones Auto Provisioning Guide.
The phones can be configured to upload log files (log files provide a history of phone events), call log files and con-
tact files to the provisioning server. You can also configure a directory for each of these three files respectively.
Topics
Auto Provisioning Settings Configuration
User-Triggered Provisioning Settings Configuration
Auto Provisioning Settings Configuration
The following table lists the parameters you can use to configure settings for auto provisioning.
Parameter
static.auto_provision.attempt_expired_time <y0000000000xx>.cfg
Description
It configures the timeout (in seconds) to transfer a file via auto provisioning.
Note: It has a higher priority than the value defined by the parameter “static.network.attempt_expired_
time”.
Permitted
Values
Integer from 1 to 300
Default
20
Web UI
Settings > Auto Provision > Attempt Expired Time(s)
Parameter
static.network.attempt_expired_time
[1]
<y0000000000xx>.cfg
Description
It configures the timeout (in seconds) to transfer a file for HTTP/HTTPS connection.

Yealink SIP-T43U Specifications

General

Mounting	Desk/Wall
Handset type	Wired handset
Product type	IP Phone
Product color	Gray
Wall mountable	Yes
Sustainability certificates	REACH, RoHS
AC adapter input voltage	100 - 240 V
AC adapter output current	1.2 A
AC adapter output voltage	5 V
Power consumption (typical)	2.2 W
Bluetooth version	4.1
Networking standards	IEEE 802.1Q, IEEE 802.1p, IEEE 802.1x, IEEE 802.3af
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Supported network protocols	FTP/TFTP/HTTP/HTTPS, IPv6, LLDP/CDP/DHCP VLAN
USB 2.0 ports quantity	2
Lines quantity	12 lines
Phonebook capacity	1000 entries
Number of VoIP accounts	12
Voice codecs	AGC, AJB, AMR-NB, AMR-WB, G.711Mu, G.711a, G.723.1, G.726, G.729ab, OPUS, PLC, VAD, iLBC
Number of handles included	1 pc(s)
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 95 %
Display diagonal	3.7 \
Display resolution	360 x 160 pixels
Dual-Tone Multi-Frequency (DTMF) modes	In-band, Out-of band, SIP info
Harmonized System (HS) code	85171800

Weight and Dimensions

Depth	206.2 mm
Width	224.9 mm
Height	174.9 mm
Package depth	223 mm
Package width	246 mm
Package height	120 mm
