Yealink SIP-T43U Administrator's Guide

Administrator’s Guide for SIP-T2 Series/T4 Series/T5 Series/CP920 IP Phones
344
Description
It configures the matching pattern used to identify the replaced string of the caller's phone number.
Permitted
Values
Regular Expression
Default
Blank
Related
Parameters
phone_setting.reverse_lookup.incoming_call.replace.with
Supported
Devices
All phones except T48G, T46G, T42G, T41P and T29G
Parameter
phone_setting.reverse_lookup.incoming_call.replace.with <y0000000000xx>.cfg
Description
It configures the string used to replace the certain matched one of the caller's phone number.
Permitted
Values
String within 512 characters
Default
Blank
Related
Parameters
phone_setting.reverse_lookup.incoming_call.replace.pattern
Supported
Devices
All phones except T48G, T46G, T42G, T41P and T29G
[1]
If you change this parameter, the phone will reboot to make the change take effect.
Example: Matching Contacts with the Caller's Phone Number Using the
Regular Expression
The following example shows the configuration for matching contacts with the caller's phone number using the reg-
ular expression.
Example:
phone_setting.reverse_lookup.contact_list.replace.pattern = 0
phone_setting.reverse_lookup.contact_list.replace.with =
phone_setting.reverse_lookup.incoming_call.replace.pattern = +49
phone_setting.reverse_lookup.incoming_call.replace.with =
After provisioning, the contact number "01781296" will be replaced with "1781296". When receiving the incoming
call from "+491781296", "+491781296" will be replaced with "1781296". Then the phone screen displays the con-
tact name and the caller's phone number.

Yealink SIP-T43U Specifications

General

Mounting	Desk/Wall
Handset type	Wired handset
Product type	IP Phone
Product color	Gray
Wall mountable	Yes
Sustainability certificates	REACH, RoHS
AC adapter input voltage	100 - 240 V
AC adapter output current	1.2 A
AC adapter output voltage	5 V
Power consumption (typical)	2.2 W
Bluetooth version	4.1
Networking standards	IEEE 802.1Q, IEEE 802.1p, IEEE 802.1x, IEEE 802.3af
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Supported network protocols	FTP/TFTP/HTTP/HTTPS, IPv6, LLDP/CDP/DHCP VLAN
USB 2.0 ports quantity	2
Lines quantity	12 lines
Phonebook capacity	1000 entries
Number of VoIP accounts	12
Voice codecs	AGC, AJB, AMR-NB, AMR-WB, G.711Mu, G.711a, G.723.1, G.726, G.729ab, OPUS, PLC, VAD, iLBC
Number of handles included	1 pc(s)
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 95 %
Display diagonal	3.7 \
Display resolution	360 x 160 pixels
Dual-Tone Multi-Frequency (DTMF) modes	In-band, Out-of band, SIP info
Harmonized System (HS) code	85171800

Weight and Dimensions

Depth	206.2 mm
Width	224.9 mm
Height	174.9 mm
Package depth	223 mm
Package width	246 mm
Package height	120 mm
