Yealink SIP-T54S User Manual

Advanced Phone Features
189
The default tag is Empty if it is not configured before.
3. Press the Option soft key, and then select the Edit from the prompt list.
4. Enter the multicast IP address and port number (e.g., 224.5.6.20:10008) in the Address field.
The valid multicast IP addresses range from 224.0.0.0 to 239.255.255.255.
5. Enter the group name in the Label field.
6. Enter the desired channel in the Channel field.
The valid channel ranges from 0 to 30.
7. Press the Save soft key to accept the change.
8. Repeat steps 2 to 7, you can add more paging groups.
Paging list is configurable via web user interface at the path Directory->Multicast IP.
To delete a paging group via phone user interface:
1. Press the paging list key when the phone is idle.
2. Press or to select a desired paging group.
3. Press the Option soft key, and then select Delete from the prompt list.

Yealink SIP-T54S Specifications

General

Mounting	Desk/Wall
Handset type	Wired handset
Product type	IP Phone
Product color	Black
Wall mountable	Yes
Wi-Fi	-
Bluetooth version	2.1+EDR
Ethernet LAN interface type	Gigabit Ethernet
Display diagonal	4.3 \
Display resolution	480 x 272 pixels
Lines quantity	16 lines
Phonebook capacity	1000 entries
Number of VoIP accounts	16
AC adapter input voltage	100 - 240 V
USB 2.0 ports quantity	1
Ethernet LAN (RJ-45) ports	2
Voice codecs	G.722, G.723, G.723.1, G.726, G.729B, OPUS, iLBC
Front camera	No
Volume control	Digital
Operating temperature (T-T)	-10 - 40 °C
Operating relative humidity (H-H)	10 - 95 %
Cables included	LAN (RJ-45)
Number of handles included	1 pc(s)
Operating system installed	Linux

Weight and Dimensions

Depth	218.8 mm
Width	233 mm
Height	172.6 mm
