Yealink VC110 Admin Guide

Administrator‘s Guide for Yealink VC110 Video Conferencing Endpoint
120
bandwidths on the endpoint are: 256 kb/s, 384 kb/s, 512 kb/s, 640 kb/s, 768 kb/s, 1024
kb/s, 1280 kb/s, 1500 kb/s, 2000 kb/s, 3000 kb/s, 4000 kb/s. The specified value of the
uplink bandwidth becomes the maximum value that users can select from the pull-down
list of Bandwidth in the dial screen.
Note
Bandwidth settings parameters on the endpoint are described below:
Parameter
Description
Configuration Method
Uplink Bandwidth
Specifies the maximum
transmitting bandwidth for the
endpoint.
Default: Auto
If Auto is selected, the endpoint
will negotiate the appropriate
uplink bandwidth automatically.
Remote Control
Web User Interface
Downlink
Bandwidth
Specifies the maximum receiving
bandwidth for the endpoint.
Default: Auto
If Auto is selected, the endpoint
will negotiate the appropriate
downlink bandwidth
automatically.
Remote Control
Web User Interface
To configure bandwidth via the web user interface:
1. Click on Setting->Call Features.
2. Select the desired value from the pull-down list of Uplink Bandwidth.
The actual resolution depends on the performance of the far site, and is affected by the
quality of the communication channel.

Yealink VC110 Specifications

General

Digital zoom	4 x
Focus adjustment	Auto
Video codecs	H.264, H.263
Maximum frame rate	30 fps
Supported video modes	720p, 1080p
Video formats supported	H.263, H.264
Supported graphics resolutions	352 x 288, 704 x 576, 1280 x 720 (HD 720), 1920 x 1080 (HD 1080)
Voice codecs	G.711a, G.722, G.722.1, G.722.1C
Line-in	Yes
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Pan range	-100 - 100 °
Tilt angle range	-30 - 30 °
Security algorithms	128-bit AES, HTTPS, SRTP, SSL/TLS
Ethernet LAN data rates	10, 100 Mbit/s
Supported network protocols	TCP/IP (IPv4), DHCP/ stastic IP, HTTP/ HTTPS, SRTP/TLS, IEEE802.1X, LLDP-MED, VLAN
Current	2 A
Power consumption (max)	30 W
Power consumption (typical)	24 W
Storage temperature (T-T)	-20 - 50 °C
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	10 - 95 %

Weight and Dimensions

Depth	151.5 mm
Width	234.6 mm
Height	161 mm
Package depth	318 mm
Package width	432 mm
Package height	274 mm
Package weight	5900 g
