Yealink VC110 Admin Guide

Administrator‘s Guide for Yealink VC110 Video Conferencing Endpoint
136
To enable the hide IP address feature via the web user interface:
1. Click on Setting->General.
2. Select Enabled from the pull-down list of Hide IP Address.
3. Click Confirm to accept the change.
The IP address is hidden from the status bar of the display device.
The endpoint will log out of the web user interface automatically after being inactive for
a period of time (default: 5 minutes). You need to re-enter the user name and password
to login. You can only configure the relog offtime via the web user interface.
The relog offtime parameter is described below:
Parameter
Description
Configuration Method
ReLogOffTime
Configures the inactive time (in
minutes) before the endpoint
logs out of the web user interface
automatically.
Default: 5
Web User Interface

Yealink VC110 Specifications

General

Digital zoom	4 x
Focus adjustment	Auto
Video codecs	H.264, H.263
Maximum frame rate	30 fps
Supported video modes	720p, 1080p
Video formats supported	H.263, H.264
Supported graphics resolutions	352 x 288, 704 x 576, 1280 x 720 (HD 720), 1920 x 1080 (HD 1080)
Voice codecs	G.711a, G.722, G.722.1, G.722.1C
Line-in	Yes
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Pan range	-100 - 100 °
Tilt angle range	-30 - 30 °
Security algorithms	128-bit AES, HTTPS, SRTP, SSL/TLS
Ethernet LAN data rates	10, 100 Mbit/s
Supported network protocols	TCP/IP (IPv4), DHCP/ stastic IP, HTTP/ HTTPS, SRTP/TLS, IEEE802.1X, LLDP-MED, VLAN
Current	2 A
Power consumption (max)	30 W
Power consumption (typical)	24 W
Storage temperature (T-T)	-20 - 50 °C
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	10 - 95 %

Weight and Dimensions

Depth	151.5 mm
Width	234.6 mm
Height	161 mm
Package depth	318 mm
Package width	432 mm
Package height	274 mm
Package weight	5900 g
