Yealink VC110 Admin Guide

Configuring Endpoint Settings
153
VC110 video conferencing endpoints support camera control protocols: FECC (Far End
Camera Control). You can enable the FECC protocol for SIP call or H.323 call.
If far site wants to control the local camera, both the far site and near site should enable
the camera control protocol simultaneously. If the FECC protocol is not enabled on either
site, far-end camera control feature cannot be performed. For example, a SIP call is
established between two sites, the two sites must enable FECC (SIP) protocol
simultaneously to perform far-end camera control feature. If FECC (SIP) protocol and
FECC (H.323) protocol are both enabled, the endpoint will select the appropriate
camera control protocol according to the protocol (SIP or H.323) the call uses.
Camera control protocol parameters are described below:
Parameter
Description
Configuration Method
FECC(H.323)
Enables or disables the FECC
(H.323) protocol for far site to
control near camera.
Default: Enabled
Web User Interface
FECC(SIP)
Enables or disables the FECC
(SIP) protocol for far site to
control near camera.
Default: Disabled
Web User Interface
To configure camera control protocol via the web user interface:
1. Click on Setting->Video & Audio.
2. Select the desired value from the pull-down list of FECC(H.323).

Yealink VC110 Specifications

General

Digital zoom	4 x
Focus adjustment	Auto
Video codecs	H.264, H.263
Maximum frame rate	30 fps
Supported video modes	720p, 1080p
Video formats supported	H.263, H.264
Supported graphics resolutions	352 x 288, 704 x 576, 1280 x 720 (HD 720), 1920 x 1080 (HD 1080)
Voice codecs	G.711a, G.722, G.722.1, G.722.1C
Line-in	Yes
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Pan range	-100 - 100 °
Tilt angle range	-30 - 30 °
Security algorithms	128-bit AES, HTTPS, SRTP, SSL/TLS
Ethernet LAN data rates	10, 100 Mbit/s
Supported network protocols	TCP/IP (IPv4), DHCP/ stastic IP, HTTP/ HTTPS, SRTP/TLS, IEEE802.1X, LLDP-MED, VLAN
Current	2 A
Power consumption (max)	30 W
Power consumption (typical)	24 W
Storage temperature (T-T)	-20 - 50 °C
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	10 - 95 %

Weight and Dimensions

Depth	151.5 mm
Width	234.6 mm
Height	161 mm
Package depth	318 mm
Package width	432 mm
Package height	274 mm
Package weight	5900 g
