Yealink VC110 Admin Guide

VC110 Video Conferencing Endpoint Introduction
33
Mute Indicator LED on the VCM30 video conferencing microphone array
LED Status
Description
Solid red
The VCM30 is muted when the VC110 is during a call.
Flashing red
The VC110 is ringing.
Solid green
The VCM30 is connected to the cable hub within the
first 5 seconds.
The VC110 is placing a call.
The VCM30 is unmuted when the VC110 is during a
call.
Off
The VCM30 is not connected to the cable hub.
The VCM30 is idle.
Three are two ways to customize the configurations of your endpoint:
 Remote Control
 Web User Interface
The following describes how to configure the VC110 video conferencing endpoint via
the two methods above.
Detailed operation steps will be introduced in the feature section.
You can use the remote control and display device to configure and use the VC110
video conferencing endpoint.
For more information on the function of each key on the remote control, refer to VCR10
Remote Control on page 27. The Advanced option is only accessible to the user with the
administrator‘s permission. The default administrator password is ―0000‖.
You can customize your endpoint via the web user interface. To access the web user
interface, you need to know the user name and the administrator‘s password. The
default user name is ―admin‖ (case-sensitive), and the default password is ―0000‖. You
can also access the web user interface with user credential, which is disabled by
default. For more information on how to enable the user credential, refer to User Mode
on page173.
The endpoint uses the HTTPS protocol to access the web user interface by default. For
more information on the access protocol for web user interface access, refer to Web

Yealink VC110 Specifications

General

Digital zoom	4 x
Focus adjustment	Auto
Video codecs	H.264, H.263
Maximum frame rate	30 fps
Supported video modes	720p, 1080p
Video formats supported	H.263, H.264
Supported graphics resolutions	352 x 288, 704 x 576, 1280 x 720 (HD 720), 1920 x 1080 (HD 1080)
Voice codecs	G.711a, G.722, G.722.1, G.722.1C
Line-in	Yes
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Pan range	-100 - 100 °
Tilt angle range	-30 - 30 °
Security algorithms	128-bit AES, HTTPS, SRTP, SSL/TLS
Ethernet LAN data rates	10, 100 Mbit/s
Supported network protocols	TCP/IP (IPv4), DHCP/ stastic IP, HTTP/ HTTPS, SRTP/TLS, IEEE802.1X, LLDP-MED, VLAN
Current	2 A
Power consumption (max)	30 W
Power consumption (typical)	24 W
Storage temperature (T-T)	-20 - 50 °C
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	10 - 95 %

Weight and Dimensions

Depth	151.5 mm
Width	234.6 mm
Height	161 mm
Package depth	318 mm
Package width	432 mm
Package height	274 mm
Package weight	5900 g
