5-20 <5. Functions of CQ1 Software>
IM 80J01A01-01E
Delete Button
Delete the sample vessel type selected in “Sample Vessel Type”
menu. Default sample vessel types are key-marked and cannot be
removed by Delete Button.
Edit Button
Start editting parameters of selected sample vessel type in
“Sample Vessel Type” menu in which name and size of vessel
type can be modified. → Edit Window
Edit Window
Input parameters such as sample vessel name and dimensions.
Refer to displayed diagram in the window for dimensions to be
input.
Measure Button (Invalid when using slide glass)
Measure the bottom thickness of sample vessel. This function can
be used when 10x dry objective lens (UPLSAPO10X2) is selected.
Laser AF Bottom Detection
By checking the box, surface to detect by laser autofocus is
changed to lower surface of bottom plate of sample vessel. This is
checked when laser autofocus doesn’t operete normally. For
details of laser autofocus, please refer to page 5-28
Cell Position (Only valid when using slide glass)
Select relative position between slide glass and sample.
<Bottom>
<Top>
