YOKOGAWA CQ1 User Manual

8-4 <8. Specifications>
IM 80J01A01-01E
8.2 General Specifications
Main Unit
Type
Standard Model
Transmission Illumination Option
Confocal
Scanning
Method
Microlens enhanced dual Nipkow disk system
Scanning speed
4000 rpm
Excitation laser
wavelength
Select 1 – 4 lasers from 405 nm󳞩488 nm󳞩561 nm󳞩and 640 nm
Phase contrast
illumination
-
Option󳞷LED transmission
illumination
Camera
sCMOS󳞩2560 x 2160 pixel󳞩16.6 mm x 14.0 mm
Objective lens
Up to 6 lenses from below list are installable
Dry󳞷2x󳞩4x󳞩10x󳞩20x󳞩40x
Long working distance󳞷20x󳞩40x
Phase contrast󳞷10x󳞩20x
External
dimensions
W 600 mm x D 400 mm
x H 298 mm
W 600 mm x D 400 mm
x H 437 mm
Mass
Without Stage Heater: 38 kg
With Stage Heater: 41.3 kg
Without Stage Heater: 40 kg
With Stage Heater: 43.3 kg
Noise level
46 dB max
A-weighted sound pressure level is less than 70dB
Utility Box
External
dimensions
W 275 mm x D 432 mm x H 298 mm
Mass
18 kg
Gas Mixer
External
dimensions
W 170 mm x D 260 mm x H 280 mm
Mass
5.2 kg
Workstation for
measurement
External
dimensions
W 172 mm x D 417 mm x H 298 mm
Mass
14 kg
Measurement software
Set measurement condition; Display image data and charts, Map
imaging; Quantified data analysis; Reporting; 3D Imaging; Multi-color
imaging; Multi-position imaging
Data format: 16 bit OME-TIFF file
Operating
temperature range
CQ1
15 – 35 ℃
Gas Mixer
20 – 30 󳇾
Operating humidity
range
CQ1
20 – 70 % RH No condensing
Gas Mixer
10 – 85 % RH No condensing
Power consumption
100 – 240 VAC 50 / 60 Hz
Main Unit, Utility box 800 VA
Gas Mixer 40 VA
Workstation 400 VA
Note
Specifications are subject to change without notice.
