<2. Precautions for Use/Installation> 2-7
IM 80J01A01-01E
WARNING
 Pulling a cable wired to this instrument with a strong force may
cause damage to the cable or connected terminals on the
instrument. Provide each cable with an ample allowance so that
the input terminals on the instrument will not receive a direct
pulling force.
 Securely connect all tubes from the gas cylinder (CO
2
100%, N
2
100%) through the gas regulator to the gas inlet tube to prevent
gas leakage. It is recommended to install a gas leakage alarm
system to avoid risk by gas leakage.
CAUTION
Please refrain from applying the following processing on the CQ1
workstation. If you do, there is a risk of malfunction of this instrument.
In case, any problems happened as a result of such inappropriate
processing, you are liable for the cost of repair.
 Install patches (Windows Update, service pack, security patch) to
update operating system.
 Install any third-party software which YOKOGAWA doesn’t
specify.
 Install any third-party hardware.
 Use any third-party software and hardware.
 Connect to the internet.
2.4 Connecting the Power
Connect the plug on the other end of the power cable to a power outlet
meeting the following conditions. For the power outlet, use a 3-pole
socket with a protective grounding terminal.
Rated power-supply voltage󳞷100 to 240 VAC
Rated power frequency󳞷50 / 60 Hz
Allowable power-supply frequency fluctuation range󳞷48󳟻63Hz
Maximum power consumption󳞷Main Unit, Utility Box 800VA
Gas Mixer 40VA
Workstation 400VA
Note
Subjecting the equipment to a sudden temperature shift may cause condensation.
