<7. Trouble Shooting> 7-15
IM 80J01A01-01E
7.3 Trouble Shooting during Analyzing
Probable Cause / Corrective Action
“Pre Analysis” function does not run
after the measurement.
“Pre Analysis” function does not run
in “CQ”mode.
Change the oprerating mode from
“CQ” mode to “HDD” mode, and
then run “Pre Analysis”.
Nothing is shown in Thumbnail Chart
window.
Select well to show chart in Well
Table window
Heat map display in Well Table
window disappeares.
Heat map isn’t shown if wells are
selected in Well Table window.
Unselect wells
Cells can not be recognized.
It might be that the threshold of
binarization is too high.
First, reconfirm the intensity range
of image by using “Image Viewer
function image acquisition”
function, and, after that, reset the
threshold properly (and, set
“Object Detectivity” higher).
It might be that the range of “Size
Filter” is not porper.
Reset the range of “Size Filter”
properly with visualization of
“Chart” function.
It might be that viewer status for is
turned to undisplayed ( ).
Turn it to displayed status ( ).
(Refer to page 5-115)
It might be that Area window is
selected in ImageViewer
Recognized result is not shown in
Area window. Select Image View
window. (refer to page 5-88)
It might be that Z position that sample
doesn’t exist is shown by viewer.
Adjust Z position.
The defined line of boundary on cells
is not smooth.
It might be that the intensity on the
boundary fluctuates or is too dark.
Increase the intensity of image by
making the exposure time longer
or increasing laser output power.
To define outer envelope of the
boundary as the resultant
boundary, add “Closing Circle”
command to “Binarize Transform”
block by using “Edit” of “Analysis”
window.
To define inner envelope of the
boundary as the resultant
boundary, add “Opening Circle”
command to “Binarize Transform”
block by using “Edit” of “Analysis”
window.
How to clear recognition showing?
Turn viewer status to undisplayed
status ( ). (Refer to page 5-115)
