<4. Measurement Procedures> 4-45
IM 80J01A01-01E
4.8 Sample Measurement
In case of measurement by saved protocol, select protocol from
“Protocol” window.
Note
In case of measuring other sample in same protocol again, please load the protocol
in each time. If the protocol is not loaded, autofocus may not operate normally.
Set the viewer layout to “ImageViewer & Chart”.
Click “Rec” to start measurement. By clicking this button, imaging by
the condition set in 4.4 Imaging Setting and analyzing by the condition
set in 4.5 Analysis Protocol Setting and 4.6 Object Recognizing
Condition Setting are executed.
Image dataset and analysis dataset are saved in the folder designated
in 4.2 Basic Protocol Setting.
Show detail of protocol
To Next Page
