<5. Functions of CQ1 Software> 5-51
IM 80J01A01-01E
5.4.5 Analysis Window
Set each method and parameter of Object Detect.
(1) Wells
This function works after test imaging by “PreRec” at “Imaging” window.
Selected Sample Vessel
Diagram of sample vessel selected at “Sample window” is shown.
Imaged wells are shown in gray. Not imaged wells are shown in
black.
By clicking gray well when button is , the well is selected
for preview (red frame). By left-clicking or left-dragging wells when
button is , the wells are selected for Analysis (pink). By
right-clicking or right-dragging, selection for Analysis is canceled.
Selection of Analysis Area
Refer to above .
All Select
All imaged wells are selected for Analysis.
Clear
Selection for Analysis of all wells is canceled.
PreAnalyze
Start preliminary analysis of selected wells for Analysis.
PreAnalyze stop
Stop preliminary analysis.
Black: Not-imaged
(Unselectable)
Gray: Imaged
(Unselected)
Red frame:
Selected for Preview
Pink:
Selected for Analysis
Note
Results of preliminary analysis are not saved.
