5-90 <5. Functions of CQ1 Software>
IM 80J01A01-01E
(3) Channel Window
Separately display images of each channel from a multi-channel image
by setting Time󳞩Field and Z. Please refer to (6) View option of 5.6.9
Tool Function (page 5-120) for display modes.
