5-130 <5. Functions of CQ1 Software>
IM 80J01A01-01E
(1) Edit object detecting algorism
Object detecting algorism which was defined at “Application”
window, can be edited.
󳏀 Selection of Object
Select the object detecting algorism.
󳏁 Display of Image
Click this button to show the image of reference channel used as
input image for object detection in Analysis Viewer (refer to
following (2)).
󳏀
󳏁
󳏃
󳏂
󳏅
󳏄
󳏆
