YOKOGAWA DLM2000 Series User Manual

5-2
IM 710105-17E
5.1 List of Commands
Command Function Page
:ANALysis:PANalyze<x>:I2T:MEASu
re:I2T:VALue?
Queries an automatically measured value of a Joule integral. 5-59
:ANALysis:PANalyze<x>:I2T:RANGe
Sets or queries the measurement source window. 5-59
:ANALysis:PANalyze<x>:I2T:SCA
Le?
Queries all scaling settings. 5-59
:ANALysis:PANalyze<x>:I2T:SCALe
:CENTer
Sets or queries the center value for manual scaling. 5-60
:ANALysis:PANalyze<x>:I2T:SCALe
:MODE
Sets or queries the scaling mode. 5-60
:ANALysis:PANalyze<x>:I2T:SCALe
:SENSitivity
Sets or queries the span from the center value for manual scaling. 5-60
:ANALysis:PANalyze<x>:I2T:TRAN
ge (Time Range)
Sets or queries the measurement time period. 5-60
:ANALysis:PANalyze<x>:HARMoni
cs?
Queries all harmonic analysis settings. 5-60
:ANALysis:PANalyze<x>:HARMonics
:CCLass?
Queries all class C harmonic analysis settings. 5-60
:ANALysis:PANalyze<x>:HARMonics
:CCLass:GETLambda
Queries the current power factor for class C harmonic analysis. 5-60
:ANALysis:PANalyze<x>:HARMonics
:CCLass:LAMBda
Sets or queries the power factor for class C harmonic analysis. 5-60
:ANALysis:PANalyze<x>:HARMonics
:CCLass:MAXCurrent
Sets or queries the fundamental current value for class C harmonic analysis. 5-61
:ANALysis:PANalyze<x>:HARMonics
:CCLass:OPOWer
Sets or queries whether or not the active power for class C harmonic
analysis exceeds 25 W.
5-61
:ANALysis:PANalyze<x>:HARMonics
:CLASs
Sets or queries the class of the device under harmonic analysis. 5-61
:ANALysis:PANalyze<x>:HARMonics
:DCLass?
Queries all class D harmonic analysis settings. 5-61
:ANALysis:PANalyze<x>:HARMonics
:DCLass:POWer
Sets or queries the power value for class D harmonic analysis. 5-61
:ANALysis:PANalyze<x>:HARMonics
:DMODe
Sets or queries the harmonic analysis display mode. 5-61
:ANALysis:PANalyze<x>:HARMonics
:DETail?
Queries all harmonic analysis result list settings. 5-61
:ANALysis:PANalyze<x>:HARMonics
:DETail:DISPlay
Sets or queries the harmonic analysis result list display mode. 5-61
:ANALysis:PANalyze<x>:HARMonics
:DETail:LIST:ITEM?
Queries the items displayed in the harmonic analysis result list. 5-62
:ANALysis:PANalyze<x>:HARMonics
:DETail:LIST:VALue?
Queries all of the data for the specified analysis number in the harmonic
analysis result list.
5-62
:ANALysis:PANalyze<x>:HARMonics
:GROuping
Sets or queries the harmonic analysis grouping. 5-62
:ANALysis:PANalyze<x>:HARMonics
:SPOint
Sets or queries the harmonic analysis computation start point. 5-62
:ANALysis:PANalyze<x>:HARMonics
:SVOLtage
Sets or queries the power supply voltage for harmonic analysis. 5-62
:ANALysis:PANalyze<x>:SETup?
Queries all power supply analysis input settings. 5-62
:ANALysis:PANalyze<x>:SETup:ADE
Skew
Executes automatic deskewing for power supply analysis. 5-62
:ANALysis:PANalyze<x>:SETup:I?
Queries all current input channel settings for power supply analysis. 5-63
:ANALysis:PANalyze<x>:SETup:I:D
ESKew
Sets or queries the deskew setting of the current input channel for power
supply analysis.
5-63
:ANALysis:PANalyze<x>:SETup:I:I
NPut
Sets or queries the current input channel for power supply analysis. 5-63
:ANALysis:PANalyze<x>:SETup:I:P
ROBe
Queries all current-to-voltage conversion ratio settings for the current input
channel probe for power supply analysis.
5-63
:ANALysis:PANalyze<x>:SETup:U?
Queries all voltage input channel settings for power supply analysis. 5-63
:ANALysis:PANalyze<x>:SETup:U:D
ESKew
Sets or queries the deskew setting of the voltage input channel for power
supply analysis.
5-63
:ANALysis:PANalyze<x>:SETup:U:I
NPut
Sets or queries the voltage input channel for power supply analysis. 5-63
:ANALysis:PANalyze<x>:SETup:U:P
ROBe
Sets or queries the probe attenuation setting of the voltage input channel for
power supply analysis.
5-63
