5-6
IM 710105-17E
5.1 List of Commands
Command Function Page
COMMunicate Group
:COMMunicate?
Queries all communication settings. 5-81
:COMMunicate:HEADer
Sets or queries whether or not a header is added to the response to a query.
(Example with header:
CHANNEL1:PROBE:MODE 10
. Example without
header:
10
.)
5-81
:COMMunicate:LOCKout
Sets or clears local lockout. 5-81
:COMMunicate:OPSE(Operation
Pending Status Enable register)
Sets or queries the overlap command that is used by the
*OPC
,
*OPC?
, and
*WAI
commands.
5-81
:COMMunicate:OPSR? (Operation
Pending Status Register)
Queries the operation pending status register. 5-81
:COMMunicate:OVERlap
Sets or queries the commands that operate as overlap commands. 5-81
:COMMunicate:REMote
Sets remote or local. On is remote mode. 5-81
:COMMunicate:VERBose
Sets or queries whether the response to a query is returned fully spelled
out (example:
CHANNEL1:PROBE:MODE 10
) or using abbreviation
(example:
CHAN:PROB 10
).
5-82
:COMMunicate:WAIT
Waits for a specified extended event to occur. 5-82
:COMMunicate:WAIT?
Creates the response that is returned when a specified extended event
occurs.
5-82
CURSor Group
:CURSor?
Queries all cursor measurement settings. 5-83
:CURSor[:TY]?
Queries all cursor settings. 5-83
:CURSor[:TY]:DEGRee?
Queries all angle cursor settings. 5-83
:CURSor[:TY]:DEGRee:ALL
Collectively turns on or off the measured values of the angle cursor on the
T-Y display.
5-83
:CURSor[:TY]:DEGRee:D<x>?
Queries all angle cursor angle settings. 5-83
:CURSor[:TY]:DEGRee:D<x>:STATe
Sets or queries the on/off status of an angle cursor angle. 5-83
:CURSor[:TY]:DEGRee:D<x>:VALue?
Queries an angle cursor angle. 5-83
:CURSor[:TY]:DEGRee:DD?
Queries all of the settings for the angle difference between the angle cursors. 5-83
:CURSor[:TY]:DEGRee:DD:STATe
Setsorqueriestheon/offstatusoftheangledifferencevalueΔD,whichis
measured between the angle cursors.
5-83
:CURSor[:TY]:DEGRee:DD:VALue?
QueriestheangledifferencevalueΔD,whichismeasuredbetweentheangle
cursors.
5-83
:CURSor[:TY]:DEGRee:DV?
QueriesallofthesettingsfortheΔVvalue,whichismeasuredbetweenthe
angle cursors.
5-83
:CURSor[:TY]:DEGRee:DV:STATe
Setsorqueriestheon/offstatusoftheΔVvalue,whichismeasuredbetween
the angle cursors.
5-83
:CURSor[:TY]:DEGRee:DV:VALue?
QueriestheΔVvalue,whichismeasuredbetweentheanglecursors. 5-83
:CURSor[:TY]:DEGRee:JUMP
Makes an angle cursor in the T-Y display jump to the specified zoom
waveform.
5-83
:CURSor[:TY]:DEGRee:POSition<x>
Sets or queries the position of an angle cursor. 5-84
:CURSor[:TY]:DEGRee:REFerence
<x>
Sets or queries the position of the angle reference start point (Reference1)
or the angle reference end point (Reference2).
5-84
:CURSor[:TY]:DEGRee:RVALue
Sets or queries the reference angle. 5-84
:CURSor[:TY]:DEGRee:TRACe
Sets or queries the source waveform that you want to measure using the
angle cursors.
5-84
:CURSor[:TY]:DEGRee:UNIT
Sets or queries the unit of angle cursor measurement. 5-84
:CURSor[:TY]:DEGRee:V<x>?
Queries all angle cursor voltage settings. 5-84
:CURSor[:TY]:DEGRee:V<x>:STATe
Sets or queries the on/off status of an angle cursor voltage. 5-84
:CURSor[:TY]:DEGRee:V<x>:VALue?
Queries an angle cursor voltage. 5-84
:CURSor[:TY]:HORizontal?
QueriesallΔVcursorsettings. 5-84
:CURSor[:TY]:HORizontal:ALL
CollectivelyturnsonoroffthemeasuredvaluesoftheΔVcursorontheT-Y
display.
5-84
:CURSor[:TY]:HORizontal:DV?
QueriesallofthesettingsfortheverticalvaluesbetweentheΔVcursors. 5-84
:CURSor[:TY]:HORizontal:DV:STA
Te
Sets or queries the on/off status of the vertical value measured between the
ΔVcursors.
5-85
:CURSor[:TY]:HORizontal:DV:VAL
ue?
QueriestheverticalvaluebetweentheΔVcursors. 5-85
:CURSor[:TY]:HORizontal:POSitio
n<x>
Sets or queries the position of a vertical cursor. 5-85
:CURSor[:TY]:HORizontal:TRACe
SetsorqueriesthesourcewaveformthatyouwanttomeasureusingtheΔV
cursors.
5-85
To Next Page
