YOKOGAWA DLM4038 User Manual

5-5
IM DLM4038-17EN
Commands
1
2
3
4
5
6
App
Index
Command Function Page
:ANALysis:PMEAsure<x>:UDPRoxima
l:PERCent
Sets or queries the distal, mesial, and proximal points as percentages. 5-77
:ANALysis:PMEAsure<x>:UDPRoxima
l:UNIT
Sets or queries the distal, mesial, and proximal points as voltages. 5-77
:ANALysis:PMEAsure<x>:UMEThod
Sets or queries the high and low points. 5-77
:ANALysis:PMEAsure<x>:UNIT
Sets or queries the watthour unit. 5-77
:ANALysis:PMEAsure<x>:USER<y>?
Queries all automatic measurement settings for a Calc item. 5-77
:ANALysis:PMEAsure<x>:USER<y>:C
OUNt?
Queries the statistical processing count of the automatically measured value
of a Calc item.
5-77
:ANALysis:PMEAsure<x>:USER<y>:D
EFine
Sets or queries the expression for the automatically measured value of a
Calc item.
5-77
:ANALysis:PMEAsure<x>:USER<y>:
{MAXimum|MEAN|MINimum|SDEViati
on}?
Queries a statistical value that is calculated on the automatically measured
value of a Calc item.
5-78
:ANALysis:PMEAsure<x>:USER<y>:N
AME
Sets or queries the name of a Calc item. 5-78
:ANALysis:PMEAsure<x>:USER<y>:S
TATe
Sets or queries the on/off status of automated measurement of a Calc item. 5-78
:ANALysis:PMEAsure<x>:USER<y>:U
NIT
Sets or queries the unit of a Calc item. 5-78
:ANALysis:PMEAsure<x>:USER<y>:V
ALue?
Queries the automatically measured value of a Calc item. 5-78
:ANALysis:WAIT?
Waits for the completion of automated measurement with a set timeout. 5-78
ASETup Group
:ASETup:EXECute
Executes auto setup. 5-79
:ASETup:UNDO
Undoes auto setup. 5-79
CALibrate Group
:CALibrate?
Queries all calibration settings. 5-80
:CALibrate[:EXECute]
Executes calibration. 5-80
:CALibrate:MODE
Sets or queries the on/off status of auto calibration. 5-80
CHANnel Group
:CHANnel<x>?
Queries all vertical axis settings of a channel. 5-81
:CHANnel<x>:ASCale[:EXECute]
Executes auto scaling of a channel. 5-81
:CHANnel<x>:BWIDth
Sets or queries the input filter setting of a channel. 5-81
:CHANnel<x>:COUPling
Sets or queries the input coupling setting of a channel. 5-81
:CHANnel<x>:DESKew
Sets or queries the deskew setting of a channel. 5-81
:CHANnel<x>:DISPlay
Sets or queries the display on/off status of a channel. 5-81
:CHANnel<x>:INVert
Sets or queries the on/off status of invert mode, which inverts the waveform
display.
5-81
:CHANnel<x>:LABel?
Queries all waveform label settings of a channel. 5-81
:CHANnel<x>:LABel[:DEFine]
Sets or queries the waveform label of a channel. 5-81
:CHANnel<x>:LABel:DISPlay
Sets or queries the waveform label display on/off status of a channel. 5-82
:CHANnel<x>:LSCale?
Queries all linear scaling settings of a channel. 5-82
:CHANnel<x>:LSCale:AVALue
Sets or queries a scaling coefficient A value. 5-82
:CHANnel<x>:LSCale:BVALue
Sets or queries an offset B value. 5-82
:CHANnel<x>:LSCale:MODE
Sets or queries the on/off status of linear scaling. 5-82
:CHANnel<x>:LSCale:UNIT
Sets or queries a unit that is attached to linear scaling results. 5-82
:CHANnel<x>:OFFSet
Sets or queries the offset voltage of a channel. 5-82
:CHANnel<x>:POSition
Sets or queries the vertical position of a channel. 5-82
:CHANnel<x>:PROBe?
Queries all probe attenuation settings of a channel. 5-82
:CHANnel<x>:PROBe:DZCalibrate
Performs demagnetization and zero adjustment on each channel. 5-82
:CHANnel<x>:PROBe[:MODE]
Sets or queries the probe attenuation setting of a channel. 5-83
:CHANnel<x>:PROBe:PZCalibrate
Executes zero calibration of current probes for a channel. 5-83
:CHANnel<x>:VARiable
Sets or queries the voltage scale of a channel in 0.01 V/division steps. 5-83
:CHANnel<x>:VDIV
Sets or queries the voltage scale (in V/division) of a channel. 5-83
5.1 List of Commands
