YOKOGAWA DLM4038 User Manual

5-48
IM DLM4038-17EN
Command Function Page
:TRIGger{[:ATRigger]|:BTRigger}
:FLEXray:IDOR:ID<x>:MODE
Sets or queries the frame ID enable/disable condition, which is one of the
OR conditions, for FlexRay bus signal triggering.
5-269
:TRIGger{[:ATRigger]|:BTRigger}
:FLEXray:MODE
Sets or queries the FlexRay bus signal trigger mode. 5-270
:TRIGger{[:ATRigger]|:BTRigger}
:FLEXray:SOURce
Sets or queries the trigger source for FlexRay bus signal triggering. 5-270
:TRIGger{[:ATRigger]|:BTRigger}
:I2C?
Queries all I
2
C bus signal trigger settings. 5-270
:TRIGger{[:ATRigger]|:BTRigger}
:I2C:ADDRess?
Queries all address pattern settings for I
2
C bus signal triggering. 5-270
:TRIGger{[:ATRigger]|:BTRigger}
:I2C:ADDRess:ADDRess?
Queries all address pattern address settings for I
2
C bus signal triggering. 5-270
:TRIGger{[:ATRigger]|:BTRigger}
:I2C:ADDRess:ADDRess:BIT10ADdre
ss?
Queries all 10-bit address settings for I
2
C bus signal triggering. 5-270
:TRIGger{[:ATRigger]|:BTRigger}
:I2C:ADDRess:ADDRess:BIT10ADdre
ss:HEXa
Sets the 10-bit address for I
2
C bus signal triggering in hexadecimal notation. 5-270
:TRIGger{[:ATRigger]|:BTRigger}
:I2C:ADDRess:ADDRess:BIT10ADdre
ss:PATTern
Sets or queries the 10-bit address for I
2
C bus signal triggering in binary
notation.
5-270
:TRIGger{[:ATRigger]|:BTRigger}
:I2C:ADDRess:ADDRess:BIT7ADdre
ss?
Queries all 7-bit address settings for I
2
C bus signal triggering. 5-270
:TRIGger{[:ATRigger]|:BTRigger}
:I2C:ADDRess:ADDRess[:BIT7ADdre
ss]:HEXa
Sets the 7-bit address for I
2
C bus signal triggering in hexadecimal notation. 5-270
:TRIGger{[:ATRigger]|:BTRigger}
:I2C:ADDRess:ADDRess[:BIT7ADdre
ss]:PATTern
Sets or queries the 7-bit address for I
2
C bus signal triggering in binary
notation.
5-271
:TRIGger{[:ATRigger]|:BTRigger}
:I2C:ADDRess:ADDRess:BIT7APsub?
Queries all 7-bit + sub address settings for I
2
C bus signal triggering. 5-271
:TRIGger{[:ATRigger]|:BTRigger}
:I2C:ADDRess:ADDRess:BIT7APsub:
ADDRess?
Queries all 7-bit address settings for the 7-bit + sub address for I
2
C bus
signal triggering.
5-271
:TRIGger{[:ATRigger]|:BTRigger}
:I2C:ADDRess:ADDRess:BIT7APsub:
ADDRess:HEXa
Sets the 7-bit address for the 7-bit + sub address for I
2
C bus signal triggering
in hexadecimal notation.
5-271
:TRIGger{[:ATRigger]|:BTRigger}
:I2C:ADDRess:ADDRess:BIT7APsub:
ADDRess:PATTern
Sets or queries the 7-bit address for the 7-bit + sub address for I
2
C bus
signal triggering in binary notation.
5-271
:TRIGger{[:ATRigger]|:BTRigger}
:I2C:ADDRess:ADDRess:BIT7APsub:
SADDress?
Queries all sub address settings for the 7-bit + sub address for I
2
C bus signal
triggering.
5-271
:TRIGger{[:ATRigger]|:BTRigger}
:I2C:ADDRess:ADDRess:BIT7APsub:
SADDress:HEXa
Sets the sub address for the 7-bit + sub address for I2C bus signal triggering
in hexadecimal notation.
5-271
:TRIGger{[:ATRigger]|:BTRigger}
:I2C:ADDRess:ADDRess:BIT7APsub:
SADDress:PATTern
Sets or queries the sub address for the 7-bit + sub address for I
2
C bus signal
triggering in binary notation.
5-272
:TRIGger{[:ATRigger]|:BTRigger}
:I2C:ADDRess:ADDRess:MODE
Sets or queries the address condition enable/disable mode for I
2
C bus signal
triggering.
5-272
:TRIGger{[:ATRigger]|:BTRigger}
:I2C:ADDRess:ADDRess:PFORmat
Sets or queries the address input format, which is one of the address
conditions, for I
2
C bus signal triggering.
5-272
:TRIGger{[:ATRigger]|:BTRigger}
:I2C:ADDRess:ADDRess:TYPE
Sets or queries the address type, which is one of the address conditions, for
I
2
C bus signal triggering.
5-272
:TRIGger{[:ATRigger]|:BTRigger}
:I2C:ADDRess:DATA?
Queries all address pattern data settings for I
2
C bus signal triggering. 5-272
:TRIGger{[:ATRigger]|:BTRigger}
:I2C:ADDRess:DATA:BCOunt
Sets or queries the position for comparing data patterns for I
2
C bus signal
triggering.
5-272
:TRIGger{[:ATRigger]|:BTRigger}
:I2C:ADDRess:DATA:BMODe
Sets or queries the on/off status of the position for comparing data patterns
for I
2
C bus signal triggering.
5-272
:TRIGger{[:ATRigger]|:BTRigger}
:I2C:ADDRess:DATA:CONDition
Sets or queries the data comparison condition (true or false) for I
2
C bus
signal triggering.
5-273
5.1 List of Commands
